Rs. 140

ETAG UHF EPC GEN2 RFID E-TAG Parking TAGS 3M INLAY Alien Higgs®9-10

Condition: Brand New

DESCRIPTION

Description
M-TAG E-TAG UHF Parking TAG UHF WINDSHIELD TAG this product have so many alias. UHF RFID security label, designed for application on glass surfaces, such as the windshield of vehicles.
Thanks to the particular antenna realization and to the special adhesive used, the label is damaged irreversibly if you try to remove it from the surface to which it is applied.
It is particularly suitable for secure automatic identification function in application of vehicle access control and parking management.

M-TAG is a security label, of very simple application, which thanks to its mechanical and electrical characteristics operates as a real seal:

The adhesive for special use allows to apply the label easily and at the same time guarantees a tenacity for which the label is damaged permanently in an attempt to remove it, thereby preventing unauthorized (re) use (for example in applications of controlled access);
The presence of an integrated UHF RFID chip is used to associate an unique serial number to the label: the tag is then read at distance and the object or vehicle that is associated to it is automatically recognized, for example using fixed or portable RFID readers.
UHF CARD TAG mounts an electronic chip which has its own unique code and cannot be duplicated. This feature enables a secure and reliable automatic identification of the label, i.e. of object or vehicle associated with it.

The label face, in thermo-printable paper or PVC, can be customized by printing in black or in four-color logo, barcode or serial number.

SPECIFICATIONS

Radiofrequency communication

Frequency: UHF 860 – 960 MHz; UHF EPC Global
RF Standard: UHF: ISO/IEC 18000-6
Technology: Passive; anti collision
Tag: Alien H3
Read/Write User memory: yes, 96 bits EPC, 512 bits User Memory, 32 bits TID
Password Protection: yes
Read/Write cycles: 10000
Data retention: 10 years

Performance

Reading distance up to 8 m, writing distance up to 2 m (depending on the type of reader)
Quality: 100% performance tested

Mechanical specifications

Dimensions: 110 x 45 x 0.3 mm
Material: Thermal Paper / Sticker Printing
Adhesive Type: 3M for special purpose
Antenna: Aluminum
Operating temperature: -15 ° C / + 70 ° C
Relative humidity: ≤ 80%
Delivery of labels: Reel of 1000 or 2000 pieces / reel
Inner reel diameter: 76 mm
Reel weight: 1 kg

Customisation

Dimensions on customer’s specification
Pre-printing with logo, barcode or serial number, according to the specified layout
EPC code initialization
